Application Field
Business Cards, Advertisements etc. in various materials.
Product Features
- Web:BOPP+ Calcium Carbonate, 40~200μm
- Dryer:
- Max. temperature:110℃
- Multiple temperature control zones
- 5M/zone
- Dryer length is adjustable. - Nozzle velocity can be adjusted by converter.
- Continuous Coating
- Turn Bar Unit
Technical Parameters
- Coating Method:
- Primer:Gravure (Enclosed Doctor Blade)
- Adhesive:Reverse Gravure (Enclosed Doctor Blade) - Coating Weight (Wet):
- Primer:5~6g/㎡±1g
- Adhesive:6~9g/㎡±1g - Roll Surface Width:1800 mm
- Web Width:800~1650 mm
- Max. Unwinding & Winding Diameter:1100 mm
- Max. Unwinding & Winding Weight:1500 kg
- Mechanical Speed:250 M/min
